Product description
**In-store pick-up only, no shipping available**
Price includes $450 CO Tax Credit and requires Proof of Residency to receive your bike after payment. If you do not qualify for the CO Tax Credit you will be charged $450 when picking up your bike. You can fill out the CO EBike Tax Credit affidavit form and bring it in when picking up your bike or fill one out in the store.
Assembly fee is not included in the price of this bike. A $180 assembly fee for this bike will be added to the shopping cart at checkout.
Take your commutes to the next LEVEL. The all new Level 3 comes fully equipped with everything you need to trade your daily drives for daily rides. A rear rack and fenders ensures you can carry necessities while staying clean and dry during your rides. A front suspension fork and suspension seat post provide maximum comfort on rougher terrain. Our ACU technology provides peace of mind with GPS tracking, auto-lock, unusual movement detection, alarm system, and much more to keep your bike safe and secure. Comfortable geometry paired with an adjustable stem ensure the perfect fit, while the implementation of Ride Tune capabilities along with adjustments to Level 3's motor power curves provide up to an additional 10 miles of range compared to its predecessor. Ditch the traffic, and elevate your daily commutes with the Level 3.
Specifications
- Adjustable Stem
- Turn Signals
- 4G Connectivity
- GPS Tracking
- Keyless Battery Removal
- Alarm and Movement Detection
- Electronic Rear Wheel Lock
- Motor Power - 500W
- Up to 70 Mile Range
- Magura Hydraulic Disc Brakes
- Front Suspension Fork and Suspension Seatpost (Adjustable)
- Rack and Fenders Included
Enhanced Security meets Advanced Technology
The revolutionary Aventon Control Unit (ACU) keeps you fully protected and always connected — all at the same time. Augmented security features including Remote Lock, Geofencing and Passcode safeguards your Level 3 and deliver an ultimate peace of mind. When cruising, you can rely on GPS tracking, 4G connection and cloud synchronization to get your bike stats in real time.
Remote Lock and Geofencing
The smart remote locking functionality lets you immobilize your bike right from the Aventon app. And the Geofencing feature lets you define the areas allowed and the distances prohibited. It’s your ride and you’re always in control
Startup Password and Keyless Battery
Customize your passcode and maximize your protection. Choose from up to six inputs and with the all-new Keyless Battery, there’s one less key on your ring, so you can just hop on and bop around.
Electronic Rear Wheel Lock
Easily activate a locking mechanism that restricts the rear wheel from rotating. This adds a layer of security when leaving your bike unattended
Suspension Seatpost
The suspension seatpost with adjustable preload allows you to customize how your seatpost absorbs the impact of the road, so all you feel is the exhilaration of the ride.
Ride Tune
Stay in perfect sync with your bike. Ride Tune lets you personalize your riding style via the Aventon App. Optimize and realize the full potential of your Level 3.
Over the Air Updates
Stay in the know while on the go. Enjoy optimal performance with intelligent over-the-air software updates through the Aventon app. No need to plug in or stop at a shop. Ride on.
Rack and Fenders
Pre-installed fenders will protect you from the elements, rain or shine, while an attached rear rack means you can transport all of your essentials, whether you're heading out for a picnic or heading home from work!
Pedal Assist and Throttle
Five levels of pedal assist mean you're in charge of how much or how little electric assist you get from your ebike, while a throttle will propel you at speeds up to 20 MPH, keeping you moving when pedaling is just an afterthought!
General Info
Model | Level 3 Commuter Ebike |
---|---|
Weight | 67lbs |
Total Weight Limit | 300 lbs |
Box Size | 61x13x34 |
Rider Height | Reg - 5'3" - 5'10" Lrg - 5'10"-6'4" |
Ebike Class | Class 2 Ebike |
Water Resistance | IPX4 |
Range | Up to 70 Miles |
Battery Safety Certifications | Certified to UL 2271 |
Safety Certifications | UL Safety Certified UL 2849 |
Ideal Use | Commuting |
Pedal Assist | 3 Levels (with Ride Tune Customization) |
Frameset
Frame | 6061 Aluminum, Gravity Cast Front Triangle |
---|---|
Fork | Aventon Suspension Fork, 80mm travel, w/ lockout,coil spring. 15x100mm thru-axle, 43mm offset |
Rear Spacing | 142mm |
Fork Spacing | 110mm |
Frame Style | Step-Over |
Wheelset
Front Wheel | 27.5in, 13g, 36hole, double wall Aluminum, Thru axle, Schrader Valve, black |
---|---|
Rear Wheel | 27.5in, 12g, 36hole, double wall Aluminum, Nutted Hub Drive Motor, Scharder Valve, black |
Tires | Kenda Kwick Seven-5 Sport K1052-006 27.5 x 2.20 |
Ebike System
Motor | 36V, 500W (sustained), 864W (peak) |
---|---|
Motor Torque | 60Nm |
Display | Aventon BC280 |
Battery | Removable Internal Lithium-ion. 36V, 20Ah, 733Wh, LG 21700 cells |
Battery Weight | 8.7lbs |
Controller | 36V, 24A |
Throttle | Aventon LH Handlebar Mounted |
Sensors | Double Sided Bottom Bracket Torque Sensor |
Charger | 36V Output: 42V/ 4A |
Charging time from 0% to 100% | 5 hours |
Lights | Front and rear lights integrated |
Speed | Class 2 |
Brakes
Front Brake | Magura AT-2 Hydraulic disc brake |
---|---|
Rear Brake | Magura AT-2 Hydraulic disc brake |
Front Brake Rotor | Magura MDR-A 180mm 6 Bolt Rotor |
Rear Brake Rotor | Magura MDR-A 180mm 6 Bolt Rotor |
Drivetrain
Rear Derailleur | Shimano Altus RD-M310 |
---|---|
Shifter | Shimano 8 Speed Trigger SL-M315-8R |
Chain | 7/8 speed 120L |
Cassette | 12-32T / 8 Speed Shimano CS HG200-8 |
Chainring | 48T |
Chainring BCD | 104 |
Crankset | 3pc, 170mm crank arm |
Bottom Bracket | Square Taper, Sealed, double sided Torque Sensor 83mmx158.5mm |
Pedals | 9/16 Composite Platform |
Cockpit
Saddle | Aventon Saddle |
---|---|
Seatpost | 30.9mm Aventon Suspension Seatpost with 50mm travel |
Seatpost Clamp | 34.9mm |
Handlebars | Aluminum 31.8mm, 680mm |
Grips | Aventon Lock on grips |
Headset | Sealed Bearing Headset |
Included Accessories
Fenders | Included |
---|---|
Rear Rack | Included |
Rear Rack Weight Limit | 60lbs |
