Product description
Seeking a carbon gravel bike to elevate your riding? Warbird GRX 610 1x is that bike. Ride with less fatigue thanks to Warbird’s carbon fiber frame and Class 5 VRS™ design, which work together to reduce harsh road vibrations. Our gravel race geometry puts you in position to pedal long training miles in comfort or put down the power in pursuit of a podium spot. And you can say goodbye to overstuffed jersey pockets; Warbird's frame and fork cargo mounts are perfect for stashing ride essentials. Shift smoothly mile after mile with the Shimano GRX components, designed for the rigors of gravel riding.
Product Details
Build Kit
Frameset
| Frame | Warbird |
|---|
| Color | Gray |
|---|
| Fork | Waxwing Deluxe V2 |
|---|
Components
| Headset | FSA NO.42/ACB |
|---|
| Seatpost | Salsa Guide, zero offset |
|---|
| Stem | Salsa Guide |
|---|
| Grips/Bar Tape | Anti-slip, shock-proof silicone tape |
|---|
| Saddle | WTB Gravelier Medium, Cromoly SL, 142 x 250mm |
|---|
| Handlebar | Salsa Cowbell |
|---|
Drivetrain
| Front Derailleur | N/A |
|---|
| Rear Derailleur | Shimano GRX RX822 GS |
|---|
| Cassette | Shimano M7100, 10-45t, 12-speed |
|---|
| Chain | Shimano M7100 |
|---|
| Crankset | Shimano GRX RX610-1, 40t |
|---|
| Shifter | Shimano GRX RX610 |
|---|
| Brake Levers | Shimano GRX RX610-1, 40t |
|---|
| Brake Calipers | Shimano GRX RX400 |
|---|
| Bottom Bracket | Shimano RS500-PB |
|---|
| Rotors | Shimano RT30 (Center Lock, 160mm front and rear) |
|---|
Wheels
| Front Tire | Teravail Cannonball 700c x 42mm, Durable casing, tubeless-ready |
|---|
| Rear Tire | Teravail Cannonball 700c x 42mm, Durable casing, tubeless-ready |
|---|
| Front Hub | Shimano TC500, 12 x 100 mm |
|---|
| Rear Hub | Shimano TC500, 12 x 142 mm |
|---|
| Spoke | 2.0/1.8 gauge, black |
|---|
| Rim | WTB ST 25 mm, TCS 2.0, 28h 700c (taped w/ WTB tubeless valve and sealant included) |
|---|
Weight
| Complete Bike | 21 lb 13 oz for 56cm |
|---|
Frame Specs
| Design Wheel/Tire Sizes | 622 - 32 (700 x 32mm) |
|---|
| Alternate Wheel/Tire Sizes | 622 – 32-45 (700c x 32–45mm / 1.2–1.8”) / 584 – 47-51 (650b x 47mm–51mm / 1.85–2.0”) |
|---|
| Max Tire Outer Diameter | 700c: 716mm / 650b: 696mm (Some front derailleurs may reduce tire clearance. Check manufacturer’s specifications to confirm clearance before installing.) |
|---|
| Frame Construction | Carbon |
|---|
| Fork Construction | Carbon |
|---|
| Suspension Fork Length (Travel) | 436.7mm A2C (40mm travel) |
|---|
| Rigid Fork Length | 405mm A2C |
|---|
| Fork Offset | 50mm |
|---|
| Rear Spacing | 142mm |
|---|
| Rear Axle Size | M12 x 167mm, TP=1.5, TL=20 |
|---|
| Headset - Upper | IS41 |
|---|
| Headset - Lower | IS52 |
|---|
| Front Spacing | 100mm |
|---|
| Front Axle Size | M12 x 120mm, TP=1.5, TL=12 |
|---|
| Steerer Tube | 28.6mm |
|---|
| Crown Race | Integrated SHIS 40, 36° angle |
|---|
| Seatpost | 27.2mm |
|---|
| Seatpost Clamp | 32.0mm |
|---|
| Derailluer Hanger | 465, (QBP# FS2322) |
|---|
| Bottom Bracket | BB86 press fit |
|---|
| Crankset (Max Ring) | 1x: 44t max; 2x: 52/36t max, 46/30t minimum |
|---|
| Accessory Mounts | Downtube Accessory Mounts: Yes, one; Rack Mounts Frame: Yes; Fender Mounts Frame: Yes, required fender hardware included |
|---|
| Bottle Mounts | Frame: Frames up to 54cm: 2 in main triangle, frames 56cm and larger: 3 in main triangle; Fork: Yes, two |
|---|
| Fork Mounts | Rack Mounts Fork: Yes, low-rider; Fender Mounts Fork: Yes |
|---|
