Product description
Warbird C GRX 820 is designed around the idea that the most comfortable gravel bike is the fastest one. Its carbon frameset, gravel race geometry, and our Class 5™ VRS (vibration reduction system) soak up rocks, ruts, washboard, and more to decrease fatigue as the miles stack up. Cargo mounts on the frame and fork extend how far you can ride without resupply. Shimano GRX 820 components round it all out with a refined ride experience that will never let you down. Go forth in speed and comfort with Warbird.
Product Details
Build Kit
Frameset
| Frame | Warbird Carbon |
|---|
| Color | Burnt Orange |
|---|
| Fork | Waxwing |
|---|
Components
| Headset | FSA NO.42/ACB |
|---|
| Seatpost | Salsa Guide |
|---|
| Stem | Salsa Guide |
|---|
| Grips/Bar Tape | Velo anti-slip, shock-proof silicone tape |
|---|
| Saddle | WTB SL8 Medium Steel SL |
|---|
| Handlebar | Salsa Cowbell |
|---|
Drivetrain
| Front Derailleur | Shimano GRX RX820 |
|---|
| Rear Derailleur | Shimano GRX RX820 |
|---|
| Cassette | Shimano HG710, 11–36t, 12-speed |
|---|
| Chain | Shimano M6100 |
|---|
| Crankset | Shimano GRX RX820, 48/31t (GRX RX610, 46/30t on size 49) |
|---|
| Shifter | Shimano GRX RX820 |
|---|
| Brake Calipers | Shimano GRX RX820 |
|---|
| Rotors | Shimano RT54 (Center Lock, 160mm) |
|---|
Wheels
| Front Wheel | Shimano RS470 12 x 100mm hub, WTB EZR i23 TCS 2.0 700c rim, 28h (taped for tubeless, WTB tubeless valve included) |
|---|
| Rear Wheel | Shimano RS470 12 x 142mm hub, WTB EZR i23 TCS 2.0 700c rim, 28h (taped for tubeless, WTB tubeless valve included) |
|---|
| Front Tire | Teravail Cannonball 700c x 42mm, Durable casing, tubeless-ready |
|---|
| Rear Tire | Teravail Cannonball 700c x 42mm, Durable casing, tubeless-ready |
|---|
Weight
| Complete Bike | 21 lb, 2 oz (56cm frame) |
|---|
Frame Specs
| Design Wheel/Tire Sizes | 622 - 32 (700 x 32mm) |
|---|
| Alternate Wheel/Tire Sizes | 622 – 32-45 (700c x 32–45mm / 1.2–1.8”) / 584 – 47-51 (650b x 47mm–51mm / 1.85–2.0”) |
|---|
| Max Tire Outer Diameter | 700c: 716mm / 650b: 696mm (Some front derailleurs may reduce tire clearance. Check manufacturer’s specifications to confirm clearance before installing.) |
|---|
| Suspension Fork Length (Travel) | 436.7mm axle-to-crown (40mm travel) |
|---|
| Rigid Fork Length | 405mm |
|---|
| Fork Offset | 50mm |
|---|
| Rear Spacing | 142mm |
|---|
| Rear Axle Size | M12 x 167L, TP = 1.5, TL = 20mm |
|---|
| Front Brake (Rotor) | Flat mount 160, flat mount rear standard, 35mm thickness, 42mm bolt length |
|---|
| Headset - Upper | IS41 |
|---|
| Headset - Lower | IS52 |
|---|
| Front Spacing | 12 x 100 mm TA |
|---|
| Front Axle Size | M12 x 120L, TP = 1.5, TL = 12mm |
|---|
| Crown Race | Integrated SHIS 40, 36° angle |
|---|
| Stem Clamp | Ø28.6mm |
|---|
| Seatpost | 27.2mm |
|---|
| Seatpost Clamp | 32.0mm |
|---|
| Derailluer Hanger | Hanger 465, QBP# FS2322 |
|---|
| Bottom Bracket | BB86 PressFit |
|---|
| Crankset (Max Ring) | 1x: 44t max; 2x: 52/36t max, 46/30t minimum |
|---|
| Accessory Mounts | Rack Mounts 165 mm Low-rider compatible. Salsa Down Under rack recommended; Downtube Accessory Mount: Yes, one pair; Toptube Mounts: Yes, compatible with Salsa Toptube bag; Three-Pack Mounts: One mount per fork leg |
|---|
| Bottle Mounts | Frames up to 54cm: 2 in main triangle, frames 56cm and larger: 3 in main triangle |
|---|
| Front Fender Mounts | Yes, required fender hardware included |
|---|
| Rear Fender Mounts | Yes, required fender hardware included |
|---|
